PR PVR Blister+
Up to 20 MP High Resolution Vision
Liquid Lens Auto-FocusMicrosecond global shutter vision sensor with sub-5ms liquid lens auto-focus for variable blister pocket depths.
600 PPM
Max Blister Speed
High-speed blister web feeding with zero friction pocket handling.Upto 8 Tracks
Multi-Lane Foil Bed
Simultaneous serialization across multitrack blister arrays.Max 300mm & Min 70mm
Foil Width Range
Universal support for Alu-Alu and thermoformed PVC blisters.Plug & Play
Seamlessly Integrates with Existing Machinery
Universal mechanical interlock and electrical synchronization with leading rotary and continuous blister packers.Seamlessly Integrates with Your Packaging Line
Custom-engineered brackets and standardized PLC signals allow drop-in installation on all major Indian and international blister packers.
Zero-Defect Line Execution & Rejection
Every critical process is sensor-verified to prevent defect escapes and maintain rigorous GMP compliance.
01Precision Rejection with Log Data
High-speed pneumatic blowing / flipper mechanism with dedicated downstream optical confirmation sensor ensuring zero defective blister escape.
02Secure Reject Containment
Dedicated lockable SS304 stainless steel reject containment bin preventing unauthorized access and maintaining strict batch clearance.
03Interactive Alarms & Real-Time Notification
Three-color stack light tower, acoustic sounder, and live HMI popups for consecutive reject thresholds and low ink warnings.
04One-Click Recipe Changeovers
Pre-programmed digital recipes for 10-tablet, 14-tablet, alu-alu, and PVC formats. Recalls print layouts and camera strobe in 1 click.
Modular IPC Mounting Configurations
Select from 3 standard factory mounting formats designed for seamless cleanroom integration and operator ergonomics.
In-Line Format
Overhead Cartoner Mount
Mounted directly on existing blister cartoner framework with heavy-duty vibration-isolation dampers. Provides optimal overhead positioning with zero floor footprint.
Technical Specifications & Performance Data
Comprehensive electrical, mechanical, camera optics, printing, and industrial computing parameters.
| Inline Blister Packaging | ||
|---|---|---|
| Parameter | PR PVR Blister+ (Standard) | Multi-Track Sync (Up to 8 Tracks) |
| Camera Type | Cognex / Smart GigE 20MP | Multi-Camera GigE Array |
| Lens | Liquid Lens Auto Focus (6.5 to 50 mm) | Liquid Lens Auto Focus |
| Lighting | In-Built Multi-Zone Strobe | Diffuse Dome High-Speed Strobe |
| Foil Web Width Range | Min 70 mm — Max 300 mm | Up to 8-Track Multi-Lane |
| Machine Weight / Bracket | Approx. 25 kg (SS304 Bracket Assembly) | Approx. 35 kg (Multi-Head Assembly) |
| Print Resolution | Up to 600 DPI |
| Print Height | 12.5 mm to 25.4 mm (Up to 1 Inch Head) |
| Power Supply | 100–240 VAC, 50/60 Hz, 2A |
| Connectivity | Gigabit Ethernet |
| Printer Type | TIJ & Laser |
| Max No. of Heads | Up to 8 Heads |
| Power Supply | 24 VDC (DC/DC/DC versions) |
| Connectivity | Gigabit Ethernet |
| Memory | Up to 24 KB |
| Protection | Industrial-grade |
| Digital Inputs | 14 DI CPU-Integrated |
| Digital Outputs | 10 DO CPU-Integrated |
| Algorithms | OCR Max, IDMax, 2DMax, Stacked Symbologies |
| Connectivity | Gigabit Ethernet |
| Power Supply | 24 VDC ±10%, approx 3–5 W |
| Touchscreen | Yes |
| Processor | Intel i5 |
| OS | Windows IoT |
| SSD / RAM | 500 / 16 GB |
