PR PVR Strip+
Up to 20 MP High Resolution Vision
Liquid Lens & Micro-Pinhole DetectionHigh-speed 20MP vision inspection across foil strip webs capturing micro-defects, porosity, and print quality at full line speed.
600 PPM
Max Packaging Speed
High-speed continuous web motion for maximum production throughput.Upto 8 Tracks
Multi-Track Synchronized Web
Simultaneous multi-lane serialization and vision verification.Max 600mm & Min 70mm
Foil Web Width Range
Universal web width accommodation from narrow to wide multi-lane formats.Plug & Play
Seamlessly Integrates with Existing Machinery
Universal mechanical interlock and electrical synchronization with leading strip packaging lines.Seamlessly Integrates with Your Packaging Line
Custom-engineered brackets and standardized PLC signals allow drop-in installation on all major Indian and international blister packers.
Zero-Defect Line Execution & Rejection
Every critical process is sensor-verified to prevent defect escapes and maintain rigorous GMP compliance.
01No Fill / Pinhole Detect & Rejection
Optical transmission sensor verifies tablet presence inside foil pockets while high-sensitivity vision spots micro-punctures and foil porosity before sealing.
02Secure Reject Containment
Dedicated lockable SS304 rejection bin with dual-sensor bin-full verification and pneumatic gate to ensure zero defective strips escape into packaging.
03Interactive Alarms & Real-Time Notification
Three-color stack light tower, acoustic sounder, and live HMI popups for consecutive reject thresholds, pouch errors, and low ink warnings.
04One-Click Recipe Changeovers
Pre-programmed digital recipes for various strip pocket layouts and foil dimensions. Recalls print layouts, track configs, and strobe in 1 click.
Modular IPC Mounting Configurations
Select from 3 standard factory mounting formats designed for seamless cleanroom integration and operator ergonomics.
In-Line Format
Overhead Strip Packer Mount
Mounted directly on existing strip packaging frame with heavy-duty vibration-isolation dampers. Provides optimal overhead positioning.
Technical Specifications & Performance Data
Comprehensive electrical, mechanical, camera optics, printing, and industrial computing parameters.
| Inline Strip Web Inspection | ||
|---|---|---|
| Parameter | PR PVR Strip+ (Standard) | Multi-Lane Foil Sync |
| Max Line Speed | 600 PPM | 600 PPM Continuous Web |
| Track Capacity | Up to 8 Tracks | Up to 8 Tracks Multi-Lane |
| Foil Web Width Range | Min 70 mm — Max 600 mm | Min 70 mm — Max 600 mm |
| Camera Type | Cognex ID+OCR Max | Multi-Zone 20MP Sensor |
| Lens | Liquid Lens Auto Focus | Wide-Angle Liquid Lens |
| Inspection Systems | No Fill / Pinhole Detect & Rejection | Secure Reject Containment |
| Machine Weight / Bracket | Approx. 25 kg (SS304 Assembly) | Approx. 35 kg (Heavy Duty Frame) |
| Print Resolution | Up to 600 DPI |
| Print Height | 12.5 mm per head |
| Power Supply | 100–240 VAC, 50/60 Hz, 2A |
| Connectivity | Gigabit Ethernet |
| Printer Type | TIJ & Laser |
| Max No. of Heads | Up to 8 Heads |
| Power Supply | 24 VDC (DC/DC/DC versions) |
| Connectivity | Gigabit Ethernet |
| Memory | Up to 24 KB |
| Protection | Industrial-grade |
| Digital Inputs | 14 DI CPU-Integrated |
| Digital Outputs | 10 DO CPU-Integrated |
| Algorithms | OCR Max, IDMax, 2DMax, Pinhole & Cavity |
| Connectivity | Gigabit Ethernet |
| Power Supply | 24 VDC ±10%, approx 3–5 W |
| Touchscreen | Yes |
| Processor | Intel i5 |
| OS | Windows IoT |
| SSD / RAM | 500 / 16 GB |
